Child Safety Application
Abstract
These Days parents are worried about their children’s so they want a complete track of them and monitor them all the time, This is physically not possible so we introduce Safety Monitoring system which is helpful for monitoring or tracking the child and their activities from anywhere in the world. The major issue of child missing can be solved with the help of child tracking system as well as parents who need to keep a track of their every steps, this system plays a vital role. The android application uses GPS and telephony services to locate their child’s location. This application secretly retrieves all the Call Logs, Message Details, Contact list and accurate Location without the children’s permission or without their knowledge as this application runs is in background and the major advantage of this feature is, if child reboots the Mobile phone the background process starts as the reboot is complete, so the process is never ending.
Child Safety Application This application sends all the data from the child’s phone to the server and from the server to the parent’s phone in every 10 minutes interval. This application is divided into 2 Apps, one is for the parent where they can see all the activities of their children and other is the Child Part, where the child can only see a calculator while the data is been fetched in the background without child’s knowledge.
Software Requirements: –
Front End: HTML5, CSS3, Bootstrap
Back End: PHP, MYSQL
Control End: Angular Java Script
Tools:
Android Emulator
xampp-win32-5.5.19-0-VC11
Android SDK – adt-bundle-windows-x86
IDE: Eclipse Mars
jdk-8u66-windows-i586
System Modules:
- PARENT
- Create site details
- View GPS location
- Manage sites
- CHILD
- Login
- search site
- Get GPS location
- MODULES:
Child Module
The child module is attached to child. Its primary role is to periodically receive messages and in response send messages to the parent module and alert them if the child is in danger. The child module also has a buzzer alarm that sounds whenever the child is in an alarmed state. This allows a parent to more easily locate the troubled child. The sensors that used with this module are described below.
Parent Module
The application by minimum runs the user interface, mostly for map tracking, as well as a service (Listener) that runs in the background of the smart phone application. On the child side that is client, the application is generally a service or Listener that runs in the background of the smart phone. A user, parent which acts as server, will use the interface to send a location request SMS to child. The Listener at the parent side performs one main function and that is to listen for the child’s reply for the location request. However, the Listener at child side (client) performs two main functions. One of these functions is periodically listens and gets location coordinates updates from GPS satellite or Network provider whichever more accurate. Few elements and less user interaction. This will result in a system that is simple and easy to implement and use, thus making it more user-friendly.
Usecase Diagrams:
Use case diagrams model behavior within a system and helps the developers understand of what the user require. The stick man represents what’s called an actor. Use case diagram can be useful for getting an overall view of the system and clarifying who can do and more importantly what they can’t do.
